Ice Shanty - Laser-Cut SVG Files

DIGITAL DOWNLOAD - you get the laser-cut files to make this yourself. Nothing is shipped.

The Ice Shanty is a little shed-roof fishing hut on sled runners, the kind you drag out onto the lake once the ice is safe. It has lap siding, a plank door with a two-pane window and Z-braces, a blank sign board over the door for your own lettering, a four-pane window in each side wall and a stovepipe poking through the roof. It sits on a cracked ice slab with its own fishing hole. The walls lock together with box-joint corners and tabs, so it squares itself as it goes together, and the runners lock into slots in the ice.

What you get (instant download)

• SVG cut files for 2.7 mm, 3 mm or 4 mm plywood (pick the folder that matches your calipers)
• 9 pieces on 2 boards, each 10 x 10 in
• Every piece as its own SVG, for recutting a single part
• A 9-page instruction booklet: cutting guide, board maps, parts list, 7 illustrated assembly steps and paint colors
• Finished-model mockup images

Finished size

• Ice base: 97 x 104 mm (3.8 x 4.1 in), with a 10.6 mm fishing hole
• Shanty footprint: 70 x 90 mm walls (2.8 x 3.5 in) on an 80 x 100 mm floor (3.1 x 3.9 in)
• Height: 94 mm (3.7 in) to the roof, about 4.7 in to the top of the stovepipe
• Walls: 80 mm front, 62 mm back: an 11 degree shed roof falling to the back

You'll need

• A laser cutter with at least a 10 x 10 in work area
• 2.7 mm, 3 mm or 4 mm plywood
• Wood glue, fine sandpaper, acrylic paints
• A 1/4 in dowel for the stovepipe

Laser-friendly files

Black = cut, blue = score. Part labels are single-line lettering on the score layer, so they mark in the same quick pass - no engraving.

This is a digital download. No physical items will be shipped.

License

You may cut these files as often as you like and sell finished, physical models you make from them. Please don't share, resell or give away the digital files, or sell unassembled cut kits made from them without permission.
